Free U.S. Shipping and Limited Lifetime Warranty For Endura Flap Pet Doors
|
|
|
|
|
|
| Small | Medium | Large | XL | XXL | |
|---|---|---|---|---|---|
| Breed size | Small | Medium | Large | Extra Large | Giant |
| Flap size (W × H) | 6″ × 11″ | 8″ × 15″ | 10″ × 19″ | 12″ × 23″ | 14″ × 27″ |
| Max shoulder height | Up to 18″ | Up to 22″ | Up to 27″ | Up to 31″ | Up to 37″ |
| Minimum weight | 10 lbs | 20 lbs | 20 lbs | 30 lbs | 50 lbs |
| Example breeds |
|
|
|
|
|
Example product used: Endura Flap Wall Mount Pet Door
6"w x 11"h
The entryway your dog goes through.10 1/8"w x 16 3/4"h
The outer edge of the pet door.
8 5/8" w x 15" h
The size of the hole needed to fit your pet door into your wall.8"w x 15"h
The entryway your dog goes through.12 3/16"w x 20 3/4"h
The outer edge of the pet door.
10 3/8" w x 19" h
The size of the hole needed to fit your pet door into your wall.10"w x 19"h
The entryway your dog goes through.14 3/16"w x 24 3/4"h
The outer edge of the pet door.
12 1/2" w x 23 1/16" h
The size of the hole needed to fit your pet door into your wall.12"w x 23"h
The entryway your dog goes through.16 1/4"w x 28 7/8"h
The outer edge of the pet door.
14 11/16" w x 27 1/16" h
The size of the hole needed to fit your pet door into your wall.14"w x 27"h
The entryway your dog goes through.18 1/4" w x 32 7/8" h
The outer edge of the pet door.
16 13/16" w x 31 3/16" h
The size of the hole needed to fit your pet door into your wall.| Flap Size | Flap Dimension | Rough Cut Out | Outside Frame Dimension | Recommended Pet Height |
|---|---|---|---|---|
| Small | 6" w x 11" h | 8 5/8" w x 15" h | 10 1/8" w x 16 3/4" h | 8" - 14" |
| Medium | 8" w x 15" h | 10 3/8" w x 19" h | 12 3/16" w x 20 3/4" h | 8" - 21" |
| Large | 10" w x 19" h | 12 1/2" w x 23 1/16" h | 14 3/16" w x 24 3/4" | 8" - 27" |
| XL | 12" w x 23" h | 14 11/16" w x 27 1/16" h | 16 1/4" w x 28 7/8" h | 8" - 34" |
| XXL | 14" w x 27" h | 16 13/16" w x 31 3/16" h | 18 1/4" w x 32 7/8" h | 8" - 41" |
Single flap or double flap? The double flap will provide more insulation for your home, perfect for extreme climates. With a double-flap system, there is a flap on each side of the tunnel and dead air space in between to add extra insulation. The single flap version will feature a trim frame for the exterior, and a flap frame for the interior, keeping the view from inside your home more aesthetically pleasing.
Note: Endura Flap pet doors are not recommended for use by kittens or very small dogs. Cats have been successful using Small, however, a few have found the Medium difficult to use. We would not recommend using sizes greater than medium, or any of the double flap versions, for cats.
Example product used: Endura Flap Thermo Panel 3e
6"w x 11"h
The entry way your dog goes through.10 3/16"
How wide your panel is.
3" - 4-1/2"
The distance from the bottom of the panel to the bottom of your flap.8"w x 15"h
The entry way your dog goes through.12 1/4"
How wide your panel is. 3" - 4-1/2"
The distance from the bottom of the panel to the bottom of your flap.10"w x 19"h
The entry way your dog goes through.14 1/4"
How wide your panel is.
3" - 6"
The distance from the bottom of the panel to the bottom of your flap.12"w x 23"h
The entry way your dog goes through.16-3/8"
How wide your panel is. 3" - 6"
The distance from the bottom of the panel to the bottom of your flap.14" w x 27" h
The entry way your dog goes through.18-3/8"
How wide your panel is. 3" - 7.5"
The distance from the bottom of the panel to the bottom of your flap.| Flap Size | Flap Dimension | Step Over Range | Overall Panel Width | Recommended Pet Height |
|---|---|---|---|---|
| Small | 6" w x 11" h | 3" - 4-1/2" (ships at 3") | 10-3/16" | 9" - 15" |
| Medium | 8" w x 15" h | 3" - 4-1/2" (ships at 3") | 12-1/4" | 9" - 21" |
| Large | 10" w x 19" h | 3" - 6" (ships at 4-1/2") | 14-1/4" | 9" - 27" |
| Extra Large | 12" w x 23" h | 3" - 6" (ships at 4-1/2") | 16-3/8" | 9" - 34" |
| XX Large | 14" w x 27" h | 3" - 7.5" (ships at 6") | 18-3/8" | 9" - 41" |
Note: Endura Flap is not recommended for kittens or very small dogs.
| Custom Height Minimum & Maximum Heights | ||
|---|---|---|
| Model | Minimum | Maximum |
| Small | 35" | 100" |
| Medium | 42" | 107" |
| Large | 48" | 117" |
| Extra Large | 46" | 123" |
Custom orders are final sale once built. They are essential in two situations:
While most sliding glass door track heights are in the three standard height ranges offered, some are not. In those cases, we can build a Thermo Panel 3e in a custom height to fit your specific dimension.
The second situation is when you have a side-sliding window. A sliding window is essentially a miniature sliding glass door, and you can install a custom height panel, provided the window track is at least 1" wide.
Example product used: Endura Flap Door Mount Pet Door
6"w x 11"h
The entry way your dog goes through.
10 1/8"w x 16 3/4"h
The outer edge of the pet door.
9 1/4"w x 15 1/8"h
The size of the hole needed to fit the pet door into your door.
8"w x 15"h
The entry way your dog goes through.
12 1/8"w x 20 13/16"h
The outer edge of the pet door.
11 5/16"w x 19 3/16"h
The size of the hole needed to fit the pet door into your door.
10"w x 19"h
The entry way your dog goes through.
14 3/16"w x 24 13/16"h
The outer edge of the pet door.
13 3/8"w x 23 3/16"h
The size of the hole needed to fit the pet door into your door.
12"w x 23"h
The entry way your dog goes through.
16 1/4"w x 28 7/8"h
The outer edge of the pet door.
15 1/2"w x 27 3/16"h
The size of the hole needed to fit the pet door into your door.
14" w x 27" h
The entry way your dog goes through.
18-1 ⁄ 4" w x 32-7 ⁄ 8" h
The outer edge of the pet door.
17-1 ⁄ 2" w x 31-1 ⁄ 4" h
The size of the hole needed to fit the pet door into your door.
| Flap Size | Flap Dimension | Rough Cut Out | Outside Frame Dimension | Recommended Pet Height |
|---|---|---|---|---|
| Small | 6" w x 11" h | 9 -1 ⁄ 4" w x 15-1 ⁄ 8" h | 10-1 ⁄ 8" w x 16-3 ⁄ 4" h | 8" - 14" |
| Medium | 8" w x 15" h | 11-5 ⁄ 16" w x 19-3 ⁄ 16" h | 12-1 ⁄ 8" w x 20-13 ⁄ 16" h | 8" - 21" |
| Large | 10" w x 19" h | 13-3 ⁄ 8" w x 23-3 ⁄ 16" h | 14-3 ⁄ 16" w x 24-13 ⁄ 16" h | 8" - 27" |
| XL | 12" w x 23" h | 15-1 ⁄ 2" w x 27-3 ⁄ 16" h | 16-1 ⁄ 4" w x 28-7 ⁄ 8" h | 8" - 34" |
| XXL | 14" w x 27" h | 17-1 ⁄ 2" w x 31-1 ⁄ 4" h | 18-1 ⁄ 4" w x 32-7 ⁄ 8" h | 8" - 41" |
Example product used: Thermo Sash 3e Pet Door for Sash Windows
6"w x 11”h
The entry way your dog goes through.
18 1/2"
How high you must raise your window in order to fit the panel into the track.8"w x 15"h
The entry way your dog goes through. 22 1/2"
How high you must raise your window in order to fit the panel into the track.10"w x 19"h
The entry way your dog goes through. 26 1/2"
How high you must raise your window in order to fit the panel into the track.12"w x 23"h
The entry way your dog goes through. 30 1/2”
How high you must raise your window in order to fit the panel into the track.| Flap Size | Flap Dimension | Height To Raise Window | Recommended Pet Height |
|---|---|---|---|
| Small | 6" w x 11" h | 18 1/2" | 9" - 15" |
| Medium | 8" w x 15" h | 22 1/2" | 9" - 21" |
| Large | 10" w x 19" h | 26 1/2" | 9" - 27" |
| Extra Large | 12" w x 23" h | 30 1/2" | 9" - 34" |
For your adjustment range, you need to measure the length of your sash window track from the furthest left to right. The adjustment range of your pet door should ideally have your track length in the middle. Custom orders are subject to special restrictions. The following adjustment ranges are available:
